CTU channel mapping should be taken into consideration when programming an event configuration
register. For example, if the channel value of any event configuration register is programmed to 16, it will
actually correspond to ADC channel 32 and conversion will occur for this channel.
ADC_P[15] CH15 15
ADC_S[0] CH32 16
ADC_S[1] CH33 17
ADC_S[2] CH34 18
ADC_S[3] CH35 19
ADC_S[4] CH36 20
ADC_S[5] CH37 21
ADC_S[6] CH38 22
ADC_S[7] CH39 23
ADC_S[8] CH40 24
ADC_S[9] CH41 25
ADC_S[10] CH42 26
ADC_S[11] CH43 27
ADC_S[12] CH44 28
ADC_S[13] CH45 29
ADC_S[14] CH46 30
ADC_S[15] CH47 31
ADC_X[0] CH64 : CH71 32 : 39
ADC_X[1] CH72 : CH79 40 : 47
ADC_X[2] CH80 : CH87 48 : 55
ADC_X[3] CH88 : CH95 56 : 63
Table 26-4. CTU-to-ADC channel assignment (continued)
10-bit ADC signal name 10-bit ADC channel #
Channel number in
CTU_EVTCFGRx
