MRE Margin Read Enable
MRE enables margin reads to be done. This bit, combined with MRV, enables regular user
mode reads
to be replaced by margin reads inside the Array Integrity Checks sequences. Margin reads
are only active during Array Integrity Checks; Normal User reads are not affected by MRE.
This bit is not accessible whenever CFLASH_MCR[DONE] or CFLASH_UT0[AID] are low:
reading returns indeterminate data while writing has no effect.
0: Margin reads are not enabled
1: Margin reads are enabled.
MRV Margin Read Value
If MRE is high, MRV selects the margin level that is being checked. Margin can be checked
to an erased level (MRV = 1) or to a programmed level (MRV = 0).
This bit is not accessible whenever CFLASH_MCR[DONE] or CFLASH_UT0[AID] are low:
reading returns indeterminate data while writing has no effect.
0: Zero’s (programmed) margin reads are requested (if MRE = 1).
1: One’s (erased) margin reads are requested (if MRE = 1).
EIE ECC data Input Enable
EIE enables the ECC Logic Check operation to be done. This bit is not accessible whenever
CFLASH_MCR[DONE] or CFLASH_UT0[AID] are low: reading returns indeterminate data
while writing has no effect.
0: ECC Logic Check is not enabled.
1: ECC Logic Check is enabled.
AIS Array Integrity Sequence
AIS determines the address sequence to be used during array integrity checks or Margin
Read . The default sequence (AIS=0) is meant to replicate sequences normal user code
follows, and thoroughly checks the read propagation paths. This sequence is proprietary.
The alternative sequence (AIS=1) is just logically sequential. It should be noted that the time
to run a sequential sequence is significantly shorter than the time to run the proprietary
sequence. The usage of proprietary sequence is forbidden in Margin Read. This bit is not
accessible whenever CFLASH_MCR[DONE] or CFLASH_UT0[AID] are low: reading returns
indeterminate data while writing has no effect.
0: Array Integrity sequence is proprietary sequence.
1: Array Integrity or f sequence is sequential.
AIE Array Integrity Enable
AIE set to ‘1’ starts the Array Integrity Check done on all selected and unlocked blocks.
The pattern is selected by AIS, and the MISR (CFLASH_UMISR0-4) can be checked after
the operation is complete, to determine if a correct signature is obtained.
AIE can be set only if CFLASH_MCR[ERS], CFLASH_MCR[PGM] and
CFLASH_MCR[EHV] are all low.
0: Array Integrity Checks, Margin Read and ECC Logic Checks are not enabled.
1: Array Integrity Checks, Margin Read and ECC Logic Checks are enabled.
AID Array Integrity Done
AID will be cleared upon an Array Integrity Check being enabled (to signify the operation is
on-going).
Once completed, AID will be set to indicate that the Array Integrity Check is complete. At this
time the MISR (CFLASH_UMISR0-4) can be checked.
0: Array Integrity Check is on-going.
1: Array Integrity Check is done.
Table 27-21. CFLASH_UT0 field descriptions (continued)
Field Description
