27.5.1.12 CFlash User Multiple Input Signature Register 3 (CFLASH_UMISR3)
The CFLASH_UMISR3 provides a mean to evaluate the Array Integrity.
The CFLASH_UMISR3 represents the bits 127:96 of the whole 144 bits word (2 Double Words including
ECC).
The CFLASH_UMISR3 is not accessible whenever CFLASH_MCR[DONE] or CFLASH_UT0[AID] are
low: reading returns indeterminate data while writing has no effect.
Offset: 0x00050 Access: Read/write
0123456789101112131415
R
MS0[95:80]
W
Reset
0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
MS0[79:64]
W
Reset
0000000000000000
Figure 27-15. CFlash User Multiple Input Signature Register 2 (CFLASH_UMISR2)
Table 27-26. CFLASH_UMISR2 field descriptions
Field Description
MS0[95:64] Multiple input Signature, bits 95–64
These bits represent the MISR value obtained accumulating the bits 95:64 of all the pages
read from the flash memory.
The MS can be seeded to any value by writing the CFLASH_UMISR2.
