MPC5604B/C Microcontroller Reference Manual, Rev. 8
698 Freescale Semiconductor
27.5.2.9 DFlash User Multiple Input Signature Register 0 (DFLASH_UMISR0)
The DFLASH_UMISR0 provides a means to evaluate the Array Integrity.
The DFLASH_UMISR0 represents the bits 31:0 of the whole 144 bits word (2 Double Words including
ECC).
The DFLASH_UMISR0 is not accessible whenever DFLASH_MCR[DONE] or DFLASH_UT0[AID] are
low: reading returns indeterminate data while writing has no effect.
Offset: 0x00044 Reset value: 0x0000_0000
0123456789101112131415
R
DAI[63:48]
W
Reset
0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
DAI[47:32]
W
Reset
0000000000000000
Figure 27-32. DFlash User Test 2 register (DFLASH_UT2)
Table 27-48. DFLASH_UT2 field descriptions
Field Description
DAI[63:32] Data Array Input, bits 63-32
These bits represent the input of odd word of ECC logic used in the ECC Logic Check. Bits DAI[63:32]
correspond to the 32 array bits representing Word 1 within the double word.
0: The array bit is forced at 0.
1: The array bit is forced at 1.
