MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 745
29.5.2.4 Global Configuration Register (GCR)
This register is used to make global configurations related to register protection.
Table 29-3. Soft lock bits vs. protected address
Soft lock bit Protected address
SLBR0.SLB0 MR0
SLBR0.SLB1 MR1
SLBR0.SLB2 MR2
SLBR0.SLB3 MR3
SLBR1.SLB0 MR4
SLBR1.SLB1 MR5
SLBR1.SLB2 MR6
SLBR1.SLB3 MR7
SLBR2.SLB0 MR8
... ...
Address 0x3FFC Access: Read Always Supervisor write
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R
HLB0000000UAA0000000
W
Reset
0000000000000 0 00
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
0 000000000000 0 00
W
Reset
0000000000000 0 00
Figure 29-4. Global Configuration Register (GCR)
