MPC5604B/C Microcontroller Reference Manual, Rev. 8
752 Freescale Semiconductor
SIUL PCR44 16 C3F90000 098 bits[0:15]
SIUL PCR45 16 C3F90000 09A bits[0:15]
SIUL PCR46 16 C3F90000 09C bits[0:15]
SIUL PCR47 16 C3F90000 09E bits[0:15]
SIUL PSMI0 8 C3F90000 500 bits[0:7]
SIUL PSMI4 8 C3F90000 504 bits[0:7]
SIUL PSMI8 8 C3F90000 508 bits[0:7]
SIUL PSMI12 8 C3F90000 50C bits[0:7]
SIUL PSMI16 8 C3F90000 510 bits[0:7]
SIUL IFMC0 32 C3F90000 1000 bits[0:31]
SIUL IFMC1 32 C3F90000 1004 bits[0:31]
SIUL IFMC2 32 C3F90000 1008 bits[0:31]
SIUL IFMC3 32 C3F90000 100C bits[0:31]
SIUL IFMC4 32 C3F90000 1010 bits[0:31]
SIUL IFMC5 32 C3F90000 1014 bits[0:31]
SIUL IFMC6 32 C3F90000 1018 bits[0:31]
SIUL IFMC7 32 C3F90000 101C bits[0:31]
SIUL IFMC8 32 C3F90000 1020 bits[0:31]
SIUL IFMC9 32 C3F90000 1024 bits[0:31]
SIUL IFMC10 32 C3F90000 1028 bits[0:31]
SIUL IFMC11 32 C3F90000 102C bits[0:31]
SIUL IFMC12 32 C3F90000 1030 bits[0:31]
SIUL IFMC13 32 C3F90000 1034 bits[0:31]
SIUL IFMC14 32 C3F90000 1038 bits[0:31]
SIUL IFMC15 32 C3F90000 103C bits[0:31]
SIUL IFCPR 32 C3F90000 1080 bits[0:31]
Mode Entry Module, 41 registers to protect
MC ME ME_ME 32 C3FDC000 008 bits[0:31]
MC ME ME_IM 32 C3FDC000 010 bits[0:31]
MC ME ME_TEST_MC 32 C3FDC000 024 bits[0:31]
MC ME ME_SAFE_MC 32 C3FDC000 028 bits[0:31]
MC ME ME_DRUN_MC 32 C3FDC000 02C bits[0:31]
Table 29-5. Protected registers (continued)
Module Register
Protected
size (bits)
Module base
address
Register
offset
Protected
bits
