MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 909
System Integration Unit
Lite
Clarified description of I/O pad function in overview section
Clarification: Not all GPIO pins have both input and output functions
Replaced parallel port register sections (PGPDO, PGPDI, and MPGDO), clarifying register
function and bit ordering
IEEE 1149.1 Test
Access Port Controller
Changed the code values for ACCESS_AUX_TAP_TCU and ACCESS_AUX_TAP_NPC in
the “JTAG Instructions” table
Flash Memory Added a note in thr “Censorship password register” sections
Added information on RWW-Error during stall-while-write in the “Module Configuration
Register (MCR)”
Analog-to-Digital
Converter
Updated following section:
•Overview
• Introduction
• Injected channel conversion
• Abort conversion
• ADC CTU (Cross Triggering Unit)
• Presampling
Updated following registers:
•CEOCFR
•CIMR
•WTISR
•DMAR
• PSR
•NCMR
•JCMR
•CDR
• CWSEL
•CWENR
•AWORR
Inserted "CTU triggered conversion" in the conversion list of "Functional description"
section
Replaced generic “system clock” with “peripheral set 3 clock”
added information about “ADC_1” in the “ADC sampling and conversion timing” section
Moved CWSEL, CWENR and AWORR register within “Watchdog register“ section
Inserted a footnote about OFFSHIFT field in the CTR register
Changed the access type of DSDR in "read/write"
Updated the DSD description in the DSDR field description table
Cross Triggering Unit Replaced “Channel number value mapping” table with “CTU-to-ADC Channel Assignment”
table
Removed “Control Status Register (CTU_CSR)” because the interrupt feature is not
implemented.
Cross Triggering Unit block diagram: trigger output control and output signals removed
Main Features section: Removed “Maskable interrupt generation whenever a trigger output
is generated”. Feature not implemented.
Table B-2. Changes between revisions 5 and 7 (continued)
Chapter Description
