H3C S5120-SI Series - Page 212

1-4
<Sysname> display ip interface brief vlan-interface
*down: administratively down
(s): spoofing
Interface Physical Protocol IP Address Description
Vlan-interface1 up up 6.6.6.6 Vlan-inte...
Vlan-interface2 up up 7.7.7.7 VLAN2
Table 1-2 display ip interface brief command output description
Field Description
*down: administratively down
The interface is administratively shut down with the shutdown
command.
(s) : spoofing
Spoofing attribute of the interface. It indicates that an interface
whose network layer protocol is displayed up may have no link
present or the link is set up only on demand.
Interface Interface name
Physical
Physical state of the interface, which can be
z *down: Indicates that the interface is administratively down; that
is, the interface is shut down with the shutdown command.
z down: Indicates that the interface is administratively up but its
physical state is down, which may be caused by a connection or
link failure.
z up: Indicates that both the administrative and physical states of
the interface are up.
Protocol
Link layer protocol state of the interface, which can be
z down: Indicates that the protocol state of the interface is down,
which is usually because that no IP address is assigned to the
interface.
z up: Indicates that the protocol state of the interface is up.
IP Address
IP address of the interface (If no IP address is configured,
“unassigned” is displayed.)
Description
Interface description information, for which at most 12 characters
can be displayed. If there are more that 12 characters, only the first
nine characters are displayed.
ip address
Syntax
ip address ip-address { mask | mask-length }
undo ip address [ ip-address { mask | mask-length } ]
View
Interface view
Default Level
2: System level
Parameters
ip-address: IP address of interface, in dotted decimal notation.
