1-30
Administrator device mac address:00e0-fc00-1d00
Administrator status:Up
Table 1-5 display cluster command output description
Field Description
Cluster name Name of the cluster
Role
Role of the switch in the cluster"
z Administrator: The current device is a management
device.
z Member: The current device is a member device.
Member number Member number of the switch in the cluster
Management-vlan Management VLAN of the cluster
Handshake timer Interval to send handshake packets
Handshake hold-time Value of handshake timer
IP-Pool Private IP addresses of the member devices in the cluster
cluster-mac Multicast MAC address of cluster management packets
Administrator device IP address IP address of the management device
Administrator device mac address MAC address of the management device
Administrator status State of the management device
display cluster base-topology
Syntax
display cluster base-topology [ mac-address mac-address | member-id member-number ]
View
Any view
Default Level
2: System level
Parameters
mac-address: Specifies a device by its MAC address. The system will display the standard topology
with the device as the root.
member-number: Specifies a device by its number. The system will display the standard topology with
the device as the root.
Description
Use the display cluster topology command to display the standard topology information of a cluster.
You can create a standard topology map when executing the build or auto-build command, or you can
use the topology accept command to save the current topology map as the standard topology map.
Note that this command can be executed on the management device only.
