1-4
Table 1-2 display link-aggregation member-port command output description
Field Description
Flags
One-octet LACP state flags field. From the least to the most significant
bit, they are represented by A through H as follows:
z A indicates whether LACP is enabled. 1 for enabled and 0 for
disabled.
z B indicates the timeout control value. 1 for short timeout, and 0 for
long timeout.
z C indicates whether the link is considered as aggregatable by the
sending system. 1 for true, and 0 for false.
z D indicates whether the link is considered as synchronized by the
sending system. 1 for true, and 0 for false.
z E indicates whether the sending system considers that collection of
incoming frames is enabled on the link. 1 for true and 0 for false.
z F indicates whether the sending system considers that distribution of
outgoing frames is enabled on the link. 1 for true and 0 for false.
z G indicates whether the receive state machine of the sending system
is using default operational partner information. 1 for true and 0 for
false.
z H indicates whether the receive state machine of the sending system
is in the expired state. 1 for true and 0 for false.
If a flag bit is set to 1, the corresponding English letter that otherwise is
not output is displayed.
Aggregation Interface Aggregate interface to which the current member port belongs
Local Information about the local end
Port Number Number of the port
Port Priority LACP priority of the port
Oper-key Operational key
Flag LACP protocol state flag
Remote Information about the remote end
System ID
System ID of the remote end, comprising the system LACP priority and
the system MAC address
Received LACP
Packets
Total number of LACP packets received
Illegal Total number of illegal packets
Sent LACP Packets Total number of LACP packets sent
display link-aggregation summary
Syntax
display link-aggregation summary
View
Any view
Default Level
1: Monitor level
