H3C S5120-SI Series Command Reference

1-5
Parameters
None
Description
Use the display link-aggregation summary command to display the summary information of all
aggregation groups.
You may find that information about the remote system for a static link aggregation group is either
displayed as none or not displayed at all. This is normal because this type of aggregation group is not
aware of its partner.
Examples
# Display the summary information of all aggregation groups.
<Sysname> display link-aggregation summary
Aggregation Interface Type:
BAGG -- Bridge-Aggregation, RAGG -- Route-Aggregation
Aggregation Mode: S -- Static, D -- Dynamic
Loadsharing Type: Shar -- Loadsharing, NonS -- Non-Loadsharing
Actor System ID: 0x8000, 000f-e267-6c6a
AGG AGG Partner ID Select Unselect Share
Interface Mode Ports Ports Type
-------------------------------------------------------------------------
BAGG1 S none 1 0 Shar
BAGG10 D 0x8000, 000f-e267-57ad 2 0 Shar
Table 1-3 display link-aggregation summary command output description
Field Description
Aggregation Interface Type
Aggregate interface type:
z BAGG for Layer 2 aggregate interface
z RAGG for Layer 3 aggregate interface
Aggregation Mode
Aggregation group type:
z S for static link aggregation
z D for dynamic aggregation
Loadsharing Type
Loadsharing type:
z Shar for load sharing
z NonS for non-load sharing
Actor System ID
Local system ID, which comprises the system LACP priority
and the system MAC address
AGG Interface Type and number of the aggregate interface
AGG Mode Aggregation group type
Partner ID
System ID of the partner, which comprises the system LACP
priority and the system MAC address
Select Ports Total number of selected ports
Unselect Ports Total number of unselected ports
