Intel ARCHITECTURE IA-32 User Manual

IA-32 Instruction Latency and Throughput C
C-17
FSCALE
4
60 7
FRNDINT
4
30 11
FXCH
5
01FP_MOVE
FLDZ
6
0
FINCSTP/FDECSTP
6
0
See “Table Footnotes”
Table C-8 IA-32 General Purpose Instructions
Instruction Latency
1
Throughput Execution Unit
2
CPUID 0F3n 0F2n 0x69n 0F3n 0F2n 0x69n 0F2n
ADC/SBB reg, reg 8 8 3 3
ADC/SBB reg, imm 8 6 2 2 ALU
ADD/SUB 1 0.5 0.5 0.5 ALU
AND/OR/XOR 1 0.5 0.5 0.5 ALU
BSF/BSR 16 8 2 4
BSWAP 1 7 0.5 1 ALU
BTC/BTR/BTS 8-9 1
CLI 26
CMP/TEST 1 0.5 0.5 0.5 ALU
DEC/INC 1 1 0.5 0.5 ALU
IMUL r32 10 14 4 1 3 FP_MUL
IMUL imm32 14 4 1 3 FP_MUL
IMUL 15-18 4 5
IDIV 66-80 56-70 30 23
IN/OUT
1
<225 40
continued
Table C-7 IA-32 x87 Floating-point Instructions (continued)
Instruction Latency
1
Throughput
Execution
Unit
2

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
