CenterPoint RTX (sc)
CenterPoint RTX(sc - standard cell) is a satellite-based subscription correction service.
Note – Make sure you have unlocked the service before setting it up.
1.
At the Configuration screen, tap GPS Receiver, then tap Setup. The GPSReceiver Settings
screen displays.
2.
On the Settings tab, complete the settings.
Setting Explanation
Antenna Selection Select a supported antenna type
Corrections Choose CenterPointRTX(ss)
FastRestart
On or off
FastRestart technology greatly reduces the time needed for
OmniSTAR HP/XP/G2/VBS and CenterPoint RTX
convergence. After the satellite signal has initially
converged, you can turn off the receiver. When you turn
the receiver on again, accuracy levels will be similar to those
experienced before shutdown.
Convergence Threshold Disabled
GPSOutput Tap to open the GPSOutput Settings screen to send
messages. See
GPSoutput settings (page 125)
.
3. On the Logging tab, if you want to record logs, select Record Logs.
4.
On the Radar Output tab, enter the settings.
Setting Explanation
Connector
Select Connector D to enable radar output.
The display can convert GPS speed into an analog
frequency that is identical to output from a radar speed
sensor.
Radar Frequency Rate Enter the required rate.
5. When you have completed the settings, tap OK.
