Point feature settings 6 Field feature mapping setup
Point feature settings
1. At the Feature Mapping screen, tap one of the four buttons under the Selected Features section.
The Select Feature screen displays.
2. At the top left-hand list, choose the Point feature.
3. Tap New. The Edit Area/Line/Point Feature screen displays.
4. Tap in the entry box for the name of the feature. The Enter Area/Line/Point Feature Name
screen displays.
5. Enter the name of the line and tap OK. You are returned to the Edit Area/Line/Point Feature
screen.
6.
Complete the settings for the point:
Setting Explanation
Alarm Radius
ll Displays as a solid red block when the vehicle comes within
this radius of the feature
l More serious than the warning radius. Set it to a shorter
distance.
Warning Radius
ll Distance around the feature that causes a warning message
to appear
l Displays on the screen as an orange line
Average Position Improves the quality of the point feature position
ll Yes: The display calculates the average position of the
feature over 30seconds.
l No: The display places the feature at the coordinates that
the vehicle is at when you tap the button.
150 FM-1000 Integrated Display User Guide Version 9.25, Revision B
