5 Connectivity settings Ag3000 modem
Ag3000 modem
The Ag3000 modem enables the FM-1000 integrated display to receive RTK corrections from a:
l Trimble VRS network
l Third-party RTK provider
l Continuously Operating Reference Station (CORS)
Modem activation
In the USA, the Ag3000 is bundled with a Trimble-installed AT&T card, which is tied to your Ag3000
unit and cannot be separated. You cannot use any other SIM cards with this device.
Additionally, the Ag3000 modem does not work in a CDMA network.
Outside of the USA, you must contact your local VRS Now™ or third-party cell provider for a SIM
card.
Modem setup
Activate VRS for use. See Activate features/plugins for use (page 47).
1. At the Configuration screen, select VRS and then tap Setup.
2.
The VRS Configuration screen displays.
3.
Select the VRS Server Setup tab. Enter the required settings, as provided by your Trimble VRS
Now
™
or Network RTK operator.
Setting Explanation
Server Name / Address
RTK/VRS/CORS base station broadcast name
Server Port Number Base station port number
Mount Point Base station mount point
User Name Assigned username
Password Assigned password
4. If you are inside the USA, tap OK. The Configuration screen displays. The Ag3000 modem is now
configured.
5. If you are outside the USA, select the SIMCard Setup tab. Enter the details of the SIMcard from
the card provider, then tap OK.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 137
