Trimble FM-1000 - Select an implement; Import an implement

Select an implement 7 Implement setup
8.
The Implement Setup wizard displays. See Edit implement settings (page 155) to complete the
settings.
Note – The information needed for implement setup depends on the plugins that you selected in the
previous step.
9. Tap OK. Your current configuration now displays in the Configuration screen.
To edit an implement, see Edit implement settings (page 155).
Select an implement
To select an implement that has been configured:
1.
At the Home screen, tap .
2. At the Configuration Selection screen, tap Switch next to the implement.
3. If necessary, enter the administrative password. See Passwords (page 39).
1.
At the Implement Configuration screen, select the implement you want to switch to and then
tap OK.
Note – If there is only one available implement, it is selected by default.
2. The currently selected implement is displayed in the Configuration Selection screen.
Import an implement
To import an implement:
1. Copy the implement file into the AgGPS folder on the USB drive.
2. Insert the USBdrive into the FM-1000 integrated display and then turn on the display.
3.
At the Home screen, tap .
4. At the Current Configurations screen, tap Setup.
5. If necessary, enter the Administration password. See Passwords (page 39).
6.
At the Configuration screen, select System and then tap Setup.
7. Select Data Files and then tap Manage.
8. Select Implement from the list on the left of the screen and then tap Copy.
The implements from the FieldManager screen now display in the Implement Configuration screen.
154 FM-1000 Integrated Display User Guide Version 9.25, Revision B
