Control setup 9 Field-IQ system setup
Feedback Setup tab
Setting Explanation
Shaft Encoder
Constant
Pulses per revolution.
Gear Ratio
Actual ratio of the application rate sensor to the seed meter shaft RPM.
This is the number of revolutions the application rate sensor turns for
each revolution of the seed meter.
The Gear ratio allows the system to properly figure the meter RPM.
l Calculate the gear ratio from the encoder to the metering point of
the material.
l Rawson gear ratio should be calculated from the motor to the
metering point of the material
If the gear ratio is calculated incorrectly, the system may over or under
apply even though it is showing the correct rate on the screen. You may
also have issues in the Drive Calibration screen.
Gear Ratio Use the calculator (tap
Gear Ratio Calculator
) to determine your gear ratio.
Seeds Per Disk
The number of seed openings per disk plate.
Row monitoring
Setting Explanation
Row Monitoring
l Disabled: Row monitoring is turned off.
l Blockage: Select when using an air seeder or when applying
granular material.
l Seed Count: Select for precision seeding.
Setup
l Row Sensor Enable: Turn individual row sensors on or off.
l Row Sensor Wiring: Select which wire each row sensor is wired
to.
226 FM-1000 Integrated Display User Guide Version 9.25, Revision B
