EZ-Pilot system operation 18 Operations
You can also Adjust EZ-Pilot guidance (page 403) settings during operations in the field.
Disengage EZ-Pilot system
The EZ-Pilot system can be disengaged automatically and manually.
Automatic disengagement
The EZ-Pilot system disengages automatically when:
l The vehicle is outside the engage distance set up in the Engage tab. See Engage settings for EZ-
Pilot system (page 193).
l The system is paused.
l GPS positions are lost.
l The Minimum Fix Quality setting is set to a high accuracy correction method and the system receives
low accuracy positions (such as no corrections).
Manual disengagement
To manually disengage the system, you can:
l
Tap (green) on the screen.
l Press the Engage button on the optional remote control.
l
Turn the steering wheel to override the electric motor.
When you turn the steering wheel manually, the EZ-Pilot system disengages. It is
recommended that you check this setting before you begin using the system in a new
installation. To do so:
a. Engage on a line.
b. Turn the wheel until EZ-Pilot disengages.
To make adjustments to the amount of force required to disengage the system using the
steering wheel, see Steering performance calibration (page 196).
402 FM-1000 Integrated Display User Guide Version 9.25, Revision B
