19 Diagnostics EZ-Pilot diagnostics
EZ-Pilot diagnostics
The EZ-Pilot Diagnostics screen contains the statistics for the IMD-600 and SAM-200 and inertial
information.
1.
At the Home screen, tap .
2.
At the Configuration screen, tap EZ-Pilot and then tap Diagnostics.
The EZ-Pilot Diagnostics screen displays.
IMD-600 status Explanation
Status Status of the system's connection to the IMD-600
Version Firmware version of the IMD-600
Serial Number Serial number of the IMD-600
SAM-200 status Explanation
Status Status of the system's connection to the SAM-200
Version Firmware version of the SAM-200
Serial Number Serial number of the SAM-600
Temperature Temperature of the SAM-600
Voltage
3. To view faults, tap View Fault Log.
4. To adjust the steering performance of the system, tap Steering Performance. See EZ-Pilot system
calibration (page 195).
