Trimble FM-1000 - Map settings; Sensor output settings

17 Yield Monitoring setup Map settings
Setting Explanation
these values depending on what you want the map to look
like.
Moisture Upper Limit Range from 5-40%. The working limit of the sensor if a trimble
moisture sensor is attached.
Map settings
At the Yield Monitoring Setup screen on the Map Legend tab, enter information about the yield and
moisture values to display on the Run screen.
Setting Explanation
High Yield Highest expected yield for the current event
Low Yield Lowest expected yield for the current event
High Moisture Highest expected moisture for the current event
Low Moisture Lowest expected moisture for the current event
Sensor output settings
At the Yield Monitoring Setup screen on theSerial tab, enter what output you want from the
sensors.
Setting Explanation
Baud Rate
Modulation rate of data transmission in seconds
Parity
l None:No parity bit sent
l O:Odd parity bit
l Event:Even parity bit
l Mark:Parity bit is set to mark signal condition
l Space:Party bit is set to space signal condition
Data Bits
Number of data bits to transmit
Stop Bits
Number of bits that represent the stop message. Used to identify the
end of the cropping message when transmitted by the system.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 331
