Trimble FM-1000 - CenterPoint RTX (ss)

GPS receiver settings 5 Connectivity settings
CenterPoint RTX (ss)
CenterPoint RTX(ss - standard satellite) is a satellite-based subscription correction service that
requires a subscription to OmniSTARintermediate.
Note – Make sure you have unlocked the service before setting it up.
1.
At the Configuration screen, tap GPS Receiver, then tap Setup. The GPSReceiver Settings
screen displays.
2.
On the Settings tab, complete the settings.
Setting Explanation
Antenna Selection Select a supported antenna type
Corrections
Choose CenterPointRTX(ss)
FastRestart
On or off
FastRestart technology greatly reduces the time needed for
OmniSTAR HP/XP/G2/VBS and CenterPoint RTX
convergence. After the satellite signal has initially
converged, you can turn off the receiver. When you turn
the receiver on again, accuracy levels will be similar to those
experienced before shutdown.
Note –
Do not move the vehicle from the point of system shut
down. Otherwise this feature will not work.
Convergence Threshold
Disabled
GPSOutput Tap to open the GPSOutput Settings screen to send
messages. See
GPSoutput settings (page 125)
.
3. On the Frequencies tab, enter the settings for Frequency and Baud Rate. See Frequencies and baud
rate (page 124).
4.
On the Advanced tab, only alter the settings if directed by Support.
Setting Explanation
Elevation Mask
SNR Mask
RTKBase Station Filter Enabled, Disabled
RTKBase Station CMRID Can be edited if Filter is enabled
Scintillation Filter On or Off
116 FM-1000 Integrated Display User Guide Version 9.25, Revision B
