Trimble FM-1000 - Recording with coverage; Field area feature settings

Recording with coverage 6 Field feature mapping setup
Recording with coverage
You can choose to have line features be recorded when you have enabled coverage.
1.
At the Home screen tap . The Configuration screen displays.
2.
Select System and tap Setup. The Display Setup screen displays.
3. Select Feature Mapping and tap Setup. The Feature Mapping screen displays.
4.
From the Record Line with Coverage list, choose:
ll None:The line will not automatically record when you begin logging coverage.
l As Applied:
l Fence:
5. Tap OK.
Field area feature settings
You can use area features to define areas of land as productive or unproductive. If the sprayer
passes into an area that is defined as unproductive, the boom sections turns off. This can be useful
for setting exclusion zones that you do not want to spray (such as waterways).
Setting Explanation
Name
Name of the feature
Color Select the feature appearance color
Area Type
Productive:Choose this option if the area feature will be a section of
land that can be included in area calculations.
Non-productive:Chose this option if the area is unproductive land.
Trigger Warning
No Warning:No warning displays.
Entering Area:A warning displays while you are inside the area.
Leaving Area: A warning displays while you are outside the area.
Remote Output
Set to Enabled if a signal pin is attached to the system. This enables
you to trigger a pulse to an external device when you enter or exit
this area.
See Remote Output setup (page 130) and Remote Output operation
(page 414).
Expand by
Options are:
146 FM-1000 Integrated Display User Guide Version 9.25, Revision B
