ISOBUS operation 18 Operations
ISOBUS operation
With ISOBUS, you can use the FM-1000 integrated display to control an ISO-certified implement
without an additional display. An ISO-certified implement has small computers called electronic
control units (ECUs) which send signals to the FM-1000 integrated display. An ISO-certified tractor
has a tractor ECU (TECU) installed on it. ECUs on implements enable you to control the operation:
l With the FM-1000 integrated display, using Task Controller (an optional feature). See Task
Controller operation (page 412).
l With Virtual Terminal, an on-screen window opens so you can directly access the functions
provided by the ECUs. See Virtual Terminal operation (page 413).
Task Controller operation
After you have activated Task Controller, displays on the Run screen.
1.
If you are using one of the following models, you must tap the Start or Auto button in the Virtual
Terminal screen before starting section and rate control using Task Controller.
a.
Tap to open the Virtual Terminal.
b.
Tap the appropriate button (Start or Auto).
Mode Tap...
Kuhn Moduliner Seed Drill
Auto
Kverneland Exacta TLGEOspread
Start
Rauch/Kuhn AXIS-H-EMC
Start
Rauch/Kuhn AXIS-W
Start
Vicon RO-EDWGEOspread
Start
2.
At the Run screen, tap on the right-hand side to display the Task Controller panel.
3.
Tap to begin logging coverage.
4.
Tap on the left-hand side to view the current section control.
5.
To switch between the two target rates, tap the appropriate target rate button on the
Task Controller panel.
6.
To turn section control on and off, tap the Section Control On / Off button.
412 FM-1000 Integrated Display User Guide Version 9.25, Revision B
