Setup process 14 TrueTracker setup
Implement controller setup for TrueTracker system
1.
At the Home screen, tap . The Configuration Selection screen displays.
2. Tap Edit next to the implement.
3.
At the Configuration screen, select TrueTracker and tap Setup. The Implement Controller
Setup screen displays.
4.
Complete the:
ll Vehicle settings for TrueTracker system (page 276)
l Engage settings for TrueTracker system (page 279)
l Steering settings for TrueTracker system (page 280)
Vehicle settings for TrueTracker system
Note – Your vehicle make and model were selected when your TrueTracker system was installed. If your
vehicle data is correct, there is no need to edit the vehicle settings. If your vehicle data is not correct, edit the
implement controller.
At the Implement Controller Setup screen's Vehicle tab, complete the settings.
Setting Explanation
Connector Which port on the FM-1000 integrated display the TrueTracker
NavController is communicating with.
TrueTracker on the FM-1000 integrated display only supports port C
or port D on the internal GNSS receivers. Communications for
TrueTracker are serial.
l Port C uses Internal Receiver 1
l Port D uses Internal Receiver 2
The common practice for the Autopilot/TrueTracker combination is
to use Port C for the vehicle and Port D for the implement.
Current Selection
Tap Edit if you need to change the:
l Vehicle profile
l Implement model
When you tap Edit, the Edit Implement Controller screen displays.
276 FM-1000 Integrated Display User Guide Version 9.25, Revision B
