Equipment calibration for Field-IQ 9 Field-IQ system setup
Sprayer calibration
WARNING – Moving parts during this operation. Ensure the implement is safe to operate.
To calibrate a sprayer calibrate the implement lift switch, then the modules.
Implement lift switch calibration
1. From the Field-IQ Calibration screen, select Implement Lift.
2. Raise the implement and then tap Next.
3. Lower the implement and then tap Next.
4. Tap OK to return to the Field-IQ Calibration screen.
Spraying modules calibration
Calibrate the modules to ensure that your system performs at the level you require.
The option to calibrate the Field-IQ system only displays on the Configuration screen if you have at
least one Field-IQ system Rate and Section control module installed.
1.
At the Configuration screen, select Field-IQ and then tap Calibrate.
2. At the Field-IQ Calibration screen, select the Rate and Section Control module you want to
calibrate.
Note – If you have an implement lift switch, calibrate it first.
Settings Explanation
Enter the test speed to use during calibration. The system will
apply material at the rate required to reach the Target Rate if
the vehicle travels at this speed.
Display only.
Display only.
Master Switch
Base PWMFrequency Change only if requested by support.
Dither Frequency Change only if requested by support.
Dither Amplitude Change only if requested by support.
236 FM-1000 Integrated Display User Guide Version 9.25, Revision B
