Serial NMEA messages
Note – Depending on your configuration, NMEAmessage output may require: Part number 67091, FmX to
DE9, RS232 cable (Port A or B), Part number 59043, DB9(F) to DB9(F) modem cable.
Some GPS receivers can output serial NMEA messages to an external device. For example, if you
have an external device connected to the Autopilot controller, you can have the receiver
sendGPSposition information to the device. The messages are output through the NavController
harness laptop connector.
Note – To enable NMEA output from another receiver for an optional feature, make sure the feature has
been selected from the feature list.
At the Serial NMEAMessages tab on the GPSOutput Settings screen, complete the settings and tap OK.
Setting Explanation
Message Rate
How often the message is sent. Options are:
l Off
l 1 min
l 30 sec
l 10 sec
l 1 Hz
l 3 Hz
l 5 Hz
l 10 Hz
Output Port
What port the message should be sent from. Options are:
l A (ext GPS)
l B (ext GPS)
l C(int GPS)
l D (int GPS)
l Autopilot
Baud Rate
Baud rate. Options are:
l 2400
l 4800
l 9600
l 19200
l 38400
