18 Operations Guidance pattern use
FreeForm pattern
Using the FreeForm pattern, you can create non-symmetrical guidance paths in fields that have
irregular shapes. FreeForm combines these patterns:
l Straight line guidance segments
l Curved guidance segments
With this combination, you can use the FreeForm pattern to create circular spirals or guidance lines
with curved and straight line segments for irregular-shaped fields as well as rugged topographics.
Unlike the other patterns where the next swath is repeated, you must drive and record all paths.
Create a FreeForm pattern
1.
At the Run screen, tap to open the Mapping Guidance panel.
2.
Tap Swaths. The Swath Management screen displays.
3.
Select the FreeForm tab and complete the settings.
Setting Explanation
Record Swath
ll Manually: Use the record button to record the path.
l
When Logging: Record the path when you are logging coverage.
Note –
If you have an external remote logging switch that controls
coverage logging, the system records FreeForm curves when the
remote logging switch is enabled).
U-Turn Detection
ll Auto: Do not record the U-turn at the end of a path.
l None: Do record the U-turn at the end of a path.
Delete All Removes all segments of the FreeForm pattern you have recorded.
4. Tap New FreeForm.
5.
To begin recording, you can either:
ll
Tap .
l
Tap (if you have set up to record logging coverage while you are engaged. See
Engage settings for Autopilot system (page 169), Engage settings for EZ-Pilot system (page
193) or Engage settings for EZ-Steer (page 201) and Coverage logging (page 381).
6.
To stop recording, you can:
Version 9.25, Revision B FM-1000 Integrated Display User Guide 369
