Trimble FM-1000 - Implement status

TrueTracker operation 18 Operations
l If two-state engage is Off:
ll First tap:Engages implement and vehicle steering
l Second tap:Disengages both implement and vehicle steering
l If two-state engage has been set to Implement First:
ll First tap: Engages the implement steering
l Second tap: Engages the vehicle steering
l Third tap: Disengages both implement and vehicle steering
l If two-state engage has been set to:
ll First tap: Engages the vehicle steering
l Second tap: Engages the implement steering
Color indicators
Color Engage button Explanation
Green
Main
Vehicle steering is engaged.
Smaller inner Implement steering is engaged.
Red Main
Vehicle steering cannot engage.
Smaller inner Implement steering cannot engage.
Yellow Main
Vehicle steering is ready to engage.
Smaller inner Implement steering is ready to engage.
Implement status
GPS status
Tap the second to view status on the implement receiver:
l Implement GPS Status
l Implement Correction Type
l Implement Correction Age
l Latitude
l Longitude
l Altitude
424 FM-1000 Integrated Display User Guide Version 9.25, Revision B
