6 Field feature mapping setup Line feature settings
Setting Explanation
l 1/2 swath width
l 1 swath width
Line feature settings
1. At the Feature Mapping screen, tap one of the four buttons under the Selected Features section.
The Select Feature screen displays.
2. At the top left-hand list, choose the Line feature.
3. Tap New. The Edit Area/Line/Point Feature screen displays.
4. Tap in the entry box for the name of the feature. The Enter Area/Line/Point Feature Name
screen displays.
5. Enter the name of the line and tap OK. You are returned to the Edit Area/Line/Point Feature
screen.
6.
Complete the settings for the line:
Setting Explanation
Color Select the feature appearance color
Trigger Warning
Enabled:Warning is enabled
Disabled:No warning will be issued
Remote Output
Set to Enabled if a signal pin is attached to the system. This
enables you to trigger a pulse to an external device when you
enter or exit this area.
See Remote Output setup (page 130) and Remote Output
operation (page 414).
7. Tap OK. The Feature Mapping screen displays again, showing the button of the feature you
just created.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 147
