Field-IQ system setup 9 Field-IQ system setup
Field-IQ system setup
1.
At the Configuration screen, select Field-IQ and then tap Setup.
2.
Tap the appropriate button to continue setup.
Button Tap to...
Material Setup
Set up a predefined list of materials to use in the Control
Setup or Material Assignment screens.
See Material setup (page 210).
Control Setup
Set up control locations and assign Field-IQ system
modules.
See Control setup (page 214).
Material Assignment
Assign materials that were set up in the Material Setup
screen to the Locations that were set up in the Control Setup
screen.
Material setup
When you select a material from the Available Materials list, some of its specific settings appear on the
right-hand side of the screen. This allows you to check some of the settings needing to view the
material.
Add or edit a material
Enter information about the material.
1. At the Material Setup screen, tap Add. The Material Details screen displays.
2.
At the Material tab, enter the appropriate settings and tap Next. See Material tab (page 215).
3.
At the Alarms tab, enter the alarm information and tap Next. See Alarms tab (page 211).
4.
At the Operation tab, complete the settings and tap Next. See Operation tab (page 212).
5.
At the Coefficient tab, enter the calibration value with the material. The material may have
different calibrations for different locations. This means that you will need to make a different
material for each location and name them in such a way (for example, Wheat Front Bin, Wheat
Rear Bin) that you will know which location to use them in. When you have entered the
coefficient, tap OK.
See Coefficent tab (page 213).
210 FM-1000 Integrated Display User Guide Version 9.25, Revision B
