Boundary feature settings
The FM-1000 integrated display includes the field boundary feature that enables you to map
multiple-bounded areas within a field.
Field boundaries create a separate boundary file that can be used to calculate area and control
automatic section switching at the edge of the field.
1. At the Feature Mapping screen, tap one of the Selected Features buttons. The Select Feature
screen displays.
2. From the feature list, select Area and then tap New.
3. From the list of features, select Boundary and then tap Edit. The Edit Area Feature screen
displays.
4.
Set one or more of the following the attributes for the boundary features.
Setting Explanation
Name Custom name that displays on the Feature Mapping tab.
Color Color of the boundary outline and also the infill color, if selected.
Draw as Outlined or Filled
Trigger Warning Visual and audible warning when entering or leaving the
boundary edge.
Remote Output Enabled: Restricts remote output pulses from being triggered
while outside the boundary.
Disabled:Does not restrict remote output.
See Remote Output setup (page 130).
Expand By How the boundary is actually recorded:
ll Nothing: Maps the boundary exactly at the recorded
position.
l ½ Swath Width: Expands the recorded boundary location by ½
the swath width after the boundary is closed.
l 1 Swath Width: Expands the recorded boundary location by 1
additional swath width after the boundary is closed.
148 FM-1000 Integrated Display User Guide Version 9.25, Revision B
