Trimble FM-1000 - GPS output settings

GPS output settings 11 ISOBUS setup
GPS output settings
1.
At the Home screen, tap . The Configuration screen displays.
2.
Select GPSReceiverand then tap Setup.
3. On the Settings tab, tap GPS Output.
4. On the CAN GPS tab, set:
a. The Message Rate to 5 Hz
b. The Output Port to be the CAN attached to the ISOBUS for the implement
5. Tap OK until you are back at the Home screen.
252 FM-1000 Integrated Display User Guide Version 9.25, Revision B
