Autopilot system operation 18 Operations
Disengage Autopilot system
The Autopilot t system can be disengaged automatically and manually.
Automatic disengagement
The Autopilot system disengages automatically when:
l The vehicle is outside the allowed distance from the guidance line set up in the Engage tab. See
Engage settings for Autopilot system (page 169).
l The system is paused.
l GPS positions are lost.
Manual disengagement
To manually disengage the system, you can:
l
Tap on the screen.
l
Turn the steering wheel to override the electric motor.
When you turn the steering wheel manually, the Autopilot system disengages. It is
recommended that you check this setting before you begin using the system in a new
installation. To do so:
a. Engage on a line.
b. Turn the wheel until Autopilot disengages.
To make adjustments to the amount of force required to disengage the system using the
steering wheel, see Automated Deadzone calibration (page 176).
400 FM-1000 Integrated Display User Guide Version 9.25, Revision B
