18 Operations TrueGuide operation
Using TrueGuide
1.
At the Run screen on the TrueGuide panel, tap (yellow). The right-hand button changes to
ON and the TrueGuide status changes to Waiting.
The Autopilot system acquires the line before transitioning to the TrueGuide system.
The TrueGuide system status remains at Waiting while the Autopilot system acquires the line.
After the TrueGuide system has taken control, its status changes to ON and the right-hand
button changes to AUTO.
2.
To disengage the TrueGuide system at anytime, tap OFF (the left-hand button).
Note – As soon as the TrueGuide system is disengaged, the Autopilot system immediately begins
providing all guidance.
Note – To turn on the TrueGuide system when the status is Waiting, tap ON again.
TrueGuide system status indicators
The system status displays on the TrueGuide tab between the Off / On (Auto) buttons.
TrueGuide Status Expanation
Off The TrueGuide system is off.
Disengaged The TrueGuide system is ready, but not engaged.
Waiting The Autopilot system is engaged, and the TrueGuide system is
preparing to engage after a short pause.
On The TrueGuide system has engaged and is on.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 427
