Trimble FM-1000 - Calibrate WM-Drain for cantilever plow

16 Water Management setup WM-Drain setup
Calibrate WM-Drain for cantilever plow
Follow the steps in sequence for consistent calibration results and improved performance. If you
skip steps, you may experience inconsistent results.
Step 1: Select the mode
1.
At the Configuration screen, select WM-Drain and then tap Setup. The WM-Drain Setup
screen displays.
2. On the Implement tab, from the Control Type list select Pitch Control.
3. Tap Measurements. The Tile Plow Measurements screen displays.
4. Enter all measurements as accurately as possible to the nearest 0.25 inch (1 cm).
5. Tap OK to return to the WM-Drain Setup screen.
6. On the Implement tab, enter values for Height Gain and Slope Transition.
7. Calibrate the roll offset.
Step 2:Set up the system
In the Implement tab, enter the values for Height Gain and Slope Transition Distance. See Implement
control settings (page 312).
Step 3: Calibrate Roll Offset
1.
At the Configuration screen, select WM-Drain and then tap Diagnostics. The Drainage
Diagnostics screen displays.
2. Complete the roll offset calibration using one of two methods.
Method 1
1. Park the system on a known level surface. Ensure the boot is flat on the ground.
2. Note the Roll value on the Drainage Diagnostics screen.
3.
At the Tile Measurements screen, for the RollCorrection value enter an offsetting value.
For example:
ll Current angle reading = .07°
l IMD-600 Roll reading = -0.2°
l Roll Offset = 0.9°
4.
Return to the Drainage Diagnostics screen. Wait approximately 30 seconds for the filtered
Version 9.25, Revision B FM-1000 Integrated Display User Guide 317
