Field-IQ diagnostics 19 Diagnostics
Field-IQ faults and troubleshooting
Faults
Message That Displays Explanation Possible Causes / Actions
Field-IQ devices not found. One or more Field-IQ
system devices in the
current implement
configuration are not
present.
Check:
l Implement selection
l Cabling and fuses
l Field-IQ Diagnostics to identify
missing modules
l Field-IQ Setup
New Field-IQ devices need
configuring. Please go to
the Field-IQ Setup.
The Field-IQ system cannot
be used without the master
switch box.
Check:
l Cabling
l To see if CAN has been dropped.
Check terminators.
The 12-section switch box
has been disconnected.
Sections will be controlled
automatically.
Field-IQ can operate
without the 12-section
switch box. Section
switching will depend only
on existing coverage, field
boundaries and exclusion
zones. To get on-screen
buttons for controlling
sections, cycle power to the
display.
Check:
l Cabling
l To see if CAN has been dropped.
Check terminators.
One or more Field-IQ
system devices were
disconnected.
One or more Field-IQ
system devices have lost
communication with the
system.
Check:
1. Cabling and fuses
2. Field-IQ system Diagnostics to
identify missing modules
3. Field-IQ System Setup
Rate not achievable For
current target rate, the
maximum speed is X mph.
The target application rate
cannot be achieved within
the configured maximum
RPM at the current speed.
The Field-IQ system is
Maximum flow/rpm has been set too
low for desired speed and rate.
482 FM-1000 Integrated Display User Guide Version 9.25, Revision B
