19 Diagnostics Field-IQ diagnostics
Message That Displays Explanation Possible Causes / Actions
limiting the RPM to the
configured maximum.
Target rate may not be
achieved for current target
rate, the minimum speed is
X\ mph.
At the current speed and
target application rate, the
required RPM is below the
configured minimum RPM
limit.
Minimum flow/rpm has been set to
high for desired speed and rate.
The current coverage
pattern will degrade system
performance.
A "combing" coverage
pattern is being generated
because of a mix of on and
off boom sections. This
causes generation of many
coverage polygons,
possibly leading to
degraded system
performance.
Contact Trimble support.
Hydraulic motor over
speed.
or
Hydraulic motor under
speed
The hydraulic motor is not
running at the commanded
speed.
Rate control stopped due
to hydraulic motor over
speed
or
Rate control stopped due
to hydraulic motor under
speed
The hydraulic motor was
stopped due to it not
running at commanded
speed.
Hydraulic motor stalled
Rate control has been
disabled. Toggle the master
switch to re-enable rate
control.
No RPM is being reported from
encoder.
Check the hydraulic motor.
It ran too fast (Rawson).
The hydraulic motor is not
running at the commanded
speed
Check hydraulic pressure.
Degraded GPS.
Automatic section control
The GPS positions are
Version 9.25, Revision B FM-1000 Integrated Display User Guide 483
