EZ-Steer diagnostics 19 Diagnostics
EZ-Steer diagnostics
1.
At the Home screen, tap .
2.
At the Configuration screen, tap EZ-Steer and then tap Diagnostics. The EZ-Steer Diagnostics
screen displays the SCM statistics and inertial information.
3. To view faults, tap View Fault Log.
4. To adjust the steering performance of the system, tap Steering Perf. See EZ-Steer system
calibration (page 203).
Field-IQ diagnostics
1.
At the Home screen, tap .
2.
At the Configuration screen, tap Field-IQ and then tap Diagnostics. The Field-IQ Diagnostics
screen displays.
Operations tab
On this tab, you can:
l Test optional switch box (page 394) if you are using an optional section switch box
l Enter values manually (page 393)
l Enable sections (page 393)
Status Item Explanation
Control Mode Auto or Manual
Rate Switch Mode Manual, Rate 1 or Rate 2
Applied Rate The rate being applied
Current Flow Relation of material being applied to time
Control Speed Speed you are moving
Master Switch Indicates which switches have been assigned to each section.
Tap View Error Log to see all errors listed since the last time the log was cleared.
Tap Section Test to begin a sequence of engaging each section and groups of sections.
480 FM-1000 Integrated Display User Guide Version 9.25, Revision B
