OmniSTAR VBS
OmniSTARVBS is a satellite-based subscription correction service with 6-8" (15-20 cm) accuracy.
Note – Make sure you have unlocked the service before setting it up.
1.
At the Configuration screen, tap GPS Receiver, then tap Setup. The GPSReceiver Settings
screen displays.
2.
On the Settings tab, complete the settings.
Setting Explanation
Antenna Selection Select a supported antenna type
Corrections
Choose OmniSTARVBS
GPSOutput
Tap to open the GPSOutput Settings screen to send
messages. See GPSoutput settings (page 125).
3.
On the Advanced tab, only alter the settings if directed by Support.
Setting Explanation
Elevation Mask
SNRMask
4. On the Logging tab, if you want to record logs, select Record Logs.
5.
On the Radar Output tab, enter the settings.
Setting Explanation
Connector
Select Connector D to enable radar output.
The display can convert GPS speed into an analog
frequency that is identical to output from a radar speed
sensor.
Radar Frequency Rate Enter the required rate.
6. When you have completed the settings, tap OK.
