8 Vehicle guidance setup EZ-Steer assisted steering system
Engage settings for EZ-Steer
To edit the EZ-Steer system engage settings:
1.
At the EZ-Steer Settings screen, select the Engage Options tab and complete the settings.
Setting Explanation
Minimum speed Minimum speed at which the system can engage. If the
system is engaged and the speed drops below this limit, the
system engages.
Maximum speed
Maximum speed at which the system can engage. If the
system is engaged and the speed increases above this limit,
the system disengages.
Maximum angle Maximum angle at which the system can engage. If the
vehicle approaches the swath at an angle greater than this
limit, it cannot be engaged.
Engage offline Maximum distance from the swath at which the system can
engage. If the vehicle approaches the swath at a distance
greater than this limit, it cannot be engaged.
Disengage offline Maximum distance from the swath at which the system can
remain engaged. If the vehicle drives offline greater than
this limit, the system disengages.
Engage on A-B Set up whether the system can or cannot be engaged on
the master A-B line.
Override sensitivity Amount the steering wheel must be turned manually
before the system disengages.
EZ-Steer external switch Set up the behavior of a seat or foot switch.
2. Tap OK. The Configuration screen displays.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 201
