Trimble FM-1000 - Overlap

7 Implement setup Edit implement settings
Overlap
Setting Explanation
Startoverlap Enter the amount of overlap (distance) you want when
beginning application of material. When you are in a
previously covered area driving toward an noncovered area,
the system will begin turning sections on at this distance
before reaching the non-covered area.
Allowable Side-to-Side Coverage
Overlap
Move the slider to indicate how much of a section's width can
be in a previously covered area before the system switches the
section off.
If the slider is all the way to the right, this is the maximum
overlapped area before the section is turned off.
Allowable Boundary Overlap
Move the slider to indicate how much of a section's width
must be past a boundary before the system switches the
section off. If the slider is all the way to the right, this is the
maximum overlapped area before the section is turned off.
End Overlap Enter the amount of overlap (distance) you want when
stopping application of material. When you are applying
material and driving toward a previously covered area, the
system will keep sections on until they are this far into the
previously covered area.
Infill Boundary
When you map a headland, you create an inner boundary and
an outer boundary.
l Select Inner to shut off sections when the implement
reaches the inner boundary.
l Select Outer to shut off sections when the implement
reaches the outer boundary.
Apply Latency to Boundary
Note –
For use with boundaries or
exclusion zones.
l Yes: The system takes into account a potential delay
between reaching the boundary and beginning the
application of material. The system will calculate when
application should occur (or stop) upon reaching the
boundary or exclusion zone.
l No: The system waits to start or stop application when
the boundary or exclusion zone is reached, without taking
into account potential delay in starting or stopping
mechanical equipment. Such mechanical delay could
leave a gap between the boundary and where the product
Version 9.25, Revision B FM-1000 Integrated Display User Guide 159
