Setup process 14 TrueTracker setup
Steering settings for TrueTracker system
At the Implement Controller Setup screen's Steering tab, complete the settings.
Setting Explanation
Nudge Increment or Trim
Increment
Set the amount by which the Nudge or Trim buttons move the
line back to the correct path, or by which the Trim buttons
move the vehicle position.
The guidance line can move off target (requiring Nudge) as a
result of:
l GPS position drift when you return to the field for
guidance, for example after you pause or turn off the
system
l GPS satellite constellation changes as you drive in the field
The vehicle can steer offline (requiring Trim) as a result of:
l Uneven drag on a vehicle from an unbalanced implement.
l Uneven drag on a vehicle from soil conditions.
End of Row Warning Distance
Distance before the end of row warning occurs.
Note –
Longer vehicles that take longer to turn need an earlier
warning and a greater distance.
Autosense On or Off
Valve on Speed
For vehicles operating at speeds that are:
l Normal: Select Normal > 0.4 m/s (1.3 ft/s). Additional settings
are supported only with NavController firmware versions
5.10 and later.
l Slow:Select Low > 0.1 m/s (0.3 ft/s) or Ultra low > 0.02 m/s (0.07 ft/s).
280 FM-1000 Integrated Display User Guide Version 9.25, Revision B
