Autopilot diagnostics 19 Diagnostics
Section Explanation
Enable
Reset
Details tab
Section Explanation
Diagnostics Vehicle and configuration specific diagnostics. Up to nine
diagnostics can be shown.
Accelerometers Raw voltage and scaled G-force for each of the system’s
accelerometers
Vehicle voltage Input voltage currently being fed into the Autopilot system
from the vehicle’s electrical system
Vehicle voltage Input voltage currently being fed into the Autopilot system
from the vehicle’s electrical system
Autopilot Faults screen
The Autopilot Faults screen lists all faults on the Autopilot controller. To access this screen tap View
Fault Log.
Item Explanation
Active Faults that are currently active
History Faults that have previously occurred
Cancel
Tap to close the screen.
Refresh Fault Lists
Tap to see the latest faults.
Clear History
Tap to clear historical faults.
Close &Clear Faults
Tap to clear all faults and close the screen.
Warning screen
When you are viewing the vehicle diagnostics screens, the View Warning button flashes red if there is
an active warning. To view any active warnings, tap the button.
