Implement calibration for TrueTracker system
The auto steering system must be calibrated for the implement you are using.
1.
At the Configuration screen, select TrueTracker and then tap Calibrate. The Implement
ControllerCalibration screen displays with a list of items to calibrate.
2. Select each item and tap OK.
3. Complete the calibration.
Controller orientation setup
1.
At the Implement ControllerCalibration screen, select Controller Orientation and tapOK. The
Autopilot Controller Orientation screen displays with a graphic that represents how the
controller is oriented in the cab. (If the controller is in an orthogonal orientation, a graphic of it
displays. If it is not in this orientation, no graphic will be displayed.)
The graphic of the controller is shown as though:
ll You are looking down on the vehicle from above.
l The top of the screen points to the front of the vehicle.
2. Tap the buttons to select the orientation of the controller. The graphic of the controller will
change as you tap the buttons.
3.
If the controller is set at a sloped angle, tap the Direct Entry tab. Then enter the yaw, pitch, and
roll angles of the controller.
Note – If you use direct entry to enter custom angles, the on-screen image of the controller does not
display.
4. Tap OK to accept the new orientation or tap Cancel to exit.
