Headland pattern
A headland is a straight AB Line or an A+ line pattern that is confined inside a boundary. This
boundary is called the headland.
Note – If you want to create a headland based on the A+ line pattern, select the straight line pattern and then
set the A+ heading for the internal line. Then complete the following steps.
1.
At the Run screen, tap to open the Mapping Guidance panel.
2.
Tap Swaths.
3. At the Swath Management screen, select the Headlands pattern from the pattern list.In the #
Headlands entry box, enter the width of the headland boundary in swaths. For example, if you
enter 2, the headland will be two swaths wide.
4.
Tap New Headland. The Run screen displays.
