Trimble FM-1000 - General setup information

9 Field-IQ system setup General setup information
Application Main functions
l Liquid Rate Control using up to 2 Rawson drives
connected to
fixed displacement pumps,
such as CDS-
John Blue piston pumps, to change liquid rate (Field-IQ
Rawson Control Module(s) needed)
l Liquid Rate Control using either a PWM or Servo control
valve and flow meter
Spreading
l Spreading Rate Control using a Rawson Drive (Field-IQ
Rawson Control Module(s) needed)
l Spreading Rate Control using either a PWM or Servo
control valve and application rate sensor
Air seeder
l Section Control of up to 96 rows of blockage sensors
l Section Control of multiple materials simultaneously with
manual rate or prescription
l Control existing PWM, linear actuators, or servo systems
l Auxiliary sensors can read fan speed, bin level, air
pressure, and implement switches
For installation and cabling information, see FM-1000 Integrated Display Cabling Guide.
General setup information
Before starting the Field-IQ system setup, ensure that:
l All components of the system are installed on the vehicle and implement.
l Field-IQ has been activated for use. See Activate features/plugins for use (page 47).
l The implement has been set up and configured for the appropriate operation, such as planting
or spraying. See Edit implement settings (page 155).
For cabling information, see the FM-1000 Integrated Display Cabling Guide.
For operational information, see Field-IQ operation (page 385).
Version 9.25, Revision B FM-1000 Integrated Display User Guide 209
