ISOBUSsettings 11 ISOBUS setup
ISOBUSsettings
To set up ISOBUS features:
1. Connect the CANbus to the FM-1000 integrated display.
2. Activate the feature/plugin you want to use. See Optional features/plugins (page 40).
3. If you are using Task Controller, unlock the feature.
4. Set up the feature you are using. See Virtual Terminal setup (page 250) or Task Controller setup
(page 251).
5. Set up GPSspeed output. See GPS output settings (page 252).
6. Set up the specific virtual terminal for your equipment. See Equipment setup (page 253).
For operational information, see ISOBUS operation (page 412).
Virtual Terminal setup
1.
At the Home screen, tap .
2.
At the Configuration screen, select Virtual Terminal and tap Setup.
3. At the Virtual Terminal Dialog screen, select the port the CAN bus is plugged into .
4. Tap OK to return to the Configuration screen.
5. Tap OK to return to the Home screen.
For operational information, see Virtual Terminal operation (page 413).
250 FM-1000 Integrated Display User Guide Version 9.25, Revision B
