FieldLevel II Leveling 16 Water Management setup
GPS receiver setup
The FieldLevel II system uses its own GPS receiver to record the exact position of the leveling blade.
To configure this receiver:
1.
At the Configuration screen, select the GPS Receiver that is associated with FieldLevel II and
then tap Setup. The WM-Drain GPS Receiver Settings screen displays.
2. From the Receiver list, select the GPS receiver you will use for your FieldLevel system. It is
recommended that you tap Internal Primary when configuring the display as a stand-alone
FieldLevel II system, but you can use an external GPS receiver. If you are also using the
Autopilot system, it is recommended that you use Internal Secondary, as the Autopilot system
will be occupying the Internal Primary receiver.
3. From the Corrections list, select RTK for all FieldLevel II applications.
4. Set the Network ID to the same network ID that is set in the base station receiver.
5. Tap OK.
6. FieldLevel II is now configured and ready to use.
FieldLevel IIsettings
Complete the FieldLevel II settings:
l Settings tab (page 302)
l Blade Settings tab (page 304)
l Relative Heights tab (page 304)
l Valve Setup tab (page 305)
l Height Filter Tab (page 305)
Settings tab
1.
At the Configuration screen, select FieldLevel II and then tap Setup. The FieldLevelIISetup
screen displays.
2.
Select the Settings tab and complete the settings.
302 FM-1000 Integrated Display User Guide Version 9.25, Revision B
