WM-Drain setup 16 Water Management setup
Implement control settings
Implement tab
At the Implement tab, enter the appropriate settings.
Setting Explanation
Control Type
Height Control: Select if no IMD-600 slope sensor is installed, or if an
IMD-600 slope sensor is being used for roll corrections only.
Pitch Control: Select to allow the IMD-600 slope sensor to adjust for
roll and pitch corrections.
Height and Pitch: Select to allow the IMD-600 sensor to control pitch
and height.
Height Gain
The amount of pitch control used to get to the target height with
Pitch Control or Height and Pitch control types.
l A higher number will more aggressively pitch the plow if it is off
target.
l A lower number will keep the plow closer to the grade and
more slowly approach the target height.
Default value for Pitch Control is 0.2, and for Height and Pitch is 0.0.
Increase this by 0.05 increments and fine tune if the plow is not
pitching enough to achieve the target depth.
Antenna Height The distance from the antenna to the bottom of the boot.
Antenna Selection Select the appropriate antenna from the list.
Survey Height Offset The distance from the tip of the boot to the ground when the plow
is in the survey position (height and pitch cylinders both in full up
position).
Survey Point Density The distance between the collected survey mapping points.
Slope Sensor (IMD-600)
Select the serial number of the installed IMD-600 slope sensor that
is used for pitch and roll corrections. It is recommended that the
IMD-600 be installed parallel to the bottom of the boot. See FM-
1000 Integrated Display Cabling Guide.
If the serial number is not in the list, make sure the cabling is
connected to port C or port D of the display.
Click Measurements to open the Tile Plow Measurements screen and
select the appropriate settings.
Slope Transition Distance
Distance required to transition the plow to a different slope
