16 Water Management setup WM-Drain setup
Setting Explanation
increment. If you are using the Pitch Control or Height and Pitch control
type, it is recommended to set this measurement to twice the
length of the boot.
If you are on a particularly rough ground, you can increase this
distance to three or four times the boot length for smoother
operation of the pitch cylinder. If you want the plow to follow the
ground contours more closely, reduce this distance to the boot
length.
Tile Plow Measurements
At the Tile Plow Measurements screen (when you are setting up Pitch Control and Height and Pitch
control types), complete the settings and tap OK.
IMD-600 section
Setting Explanation
Label Faces The direction (Up, Down, Left, Right) that the IMD-600 label faces in
relation to the direction the plow travels during installation.
Connector Faces The direction (Left, Right, Forward, Back) that the IMD-600
connector faces in relation to the direction the plow travels during
installation.
Pitch Offset
The amount of angle or tilt (up or down) if the sensor is not installed
parallel to the bottom of the boot.
If you adjust the pitch offset, this can help correct the boot pitch if it
is not running level through the ground.
Roll Correction Corrects for static roll caused by minor variations in the sensor
mounting.
Antenna section
Setting Explanation
Horizontal The distance from the leading edge of the boot to the center line of
the antenna. The horizontal distance should be positive if the
antenna is forward from the tip of the boot and negative if it is
backward.
Vertical The distance from the bottom of the boot to the base of the
antenna dome.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 313
